    New Instant Seal Silver Liquid Gasket Seal of mechanical equipment, micro- and medium-sized axles, gearboxes, bridge box

    Ask Lasest Price
    Brand Name : Huitian
    Model Number : Instant Seal
    Certification : ISO
    Price : Negotiation
    Payment Terms : L/C, T/T
    Supply Ability : 300,000 Pcs/M
    Delivery Time : 5-8 days
    • Product Details
    • Company Profile

    New Instant Seal Silver Liquid Gasket Seal of mechanical equipment, micro- and medium-sized axles, gearboxes, bridge box

    Instant seal TDS-EN.pdf


    New Instant Seal - RTV Silicone Gasket Maker 55g/90g for gasket sealing


    Silicone gasket-free sealant is a one-component, silver grey, high-performance de-oxime type room temperature vulcanizing silicone rubber. The rubber layer is elastomeric after curing, with good resistance to changes in temperature and stress, excellent high temperature, oil and weather resistance, and other properties.


    Typical applications

    Seal of mechanical equipment, micro- and medium-sized axles, gearboxes, bridge boxes, etc. Suitable industries such as transportation, mining, electricity, and cement.


    Properties before curing

    Typical value Range

    Appearance Silver paste

    Chemical composition Polysiloxane

    Density (g/cm3) 1.38 1.3-1.5

    (GB/T13354-1992)

    Tack-free time (min) 5 5-30

    (23℃/50%RH)

    (GB/T13477.5-20)

    Pressure flow viscosity (s/10g) 5 5-20

    (0.5MPa, 23℃, 3mm)


    Properties after curing

    Tensile strength (MPa) 2.0 ≥1.0

    (GB/T528-1998)

    Elongation at break (%) 200 ≥150

    (GB/T528-1998)

    Hardness (Shore A) 40 ≥30

    (GB/T531-1999)

    Operating temperature (℃) -60-260


    Oil resistance

    Tensile strength (MPa)

    after soaking in 30# oil @125°C,24h 1.8 ≥1.0

    (GB/T528-1998)

    Elongation at break (%) 250 ≥150

    (GB/T528-1998)

    Temperature resistance

    Tensile strength after 168h at 200°C

    (MPa) (GB/T528-1998) 2.2 ≥1.0

    Elongation at break (%) 200 ≥150

    (GB/T528-1998)


    Directions for use

    Clean-up: Clean the surface and remove rust, dust, oil, etc.

    Gluing: Cut a suitable small hole in the spout of the cartridge and apply glue with a glue gun to the end face to be sealed, to form a continuous glue ring. In the case of pneumatic application, the air pressure is recommended not to exceed 0.4MPa.

    Curing: Fold the two end faces and fasten them with bolts; the initial curing time is one hour, and the full curing time is 24 hours at 25°C and 50% humidity. Longer curing time is required in colder or dry conditions.

    Storage: Unused adhesive should be stored after immediately tightening the cap and sealing the nozzle. When used again, if there is a small amount of crust on the seal, just remove it, and it won’t affect the normal use of the product. During storage, a small amount of crust may appear at the mouth of the tube, which can be removed for normal use and won’t affect the performance of the product.


    Cautions

    Keep away from children for storage.

    If the skin is accidentally exposed to the product, wipe it with a cloth and wash it with water before it cures. If the eyes are accidentally exposed to the product, rinse immediately with water.

    Use in a well-ventilated place is recommended.

    Please consult the MSDS of the product for safety information.


    Packing specification

    90g/tube, 80 tubes/carton; 55g/tube, 100 tubes/carton


    Storage

    Store at 8-28°C in a cool and dry place.

    Shelf life is 12 months.
