    5296 Two-Part Addition-Type Potting Adhesive For Power Supplies, Connectors, Sensors, Industrial Controls

    Ask Lasest Price
    Brand Name : Huitian
    Model Number : 5296
    Certification : UL,RoHS
    Price : Negotiation
    Supply Ability : 2000T/Month
    Payment Terms : L/C, T/T
    Delivery Time : 5-8 days
    • Product Details
    • Company Profile

    5296 Two-Part Addition-Type Potting Adhesive For Power Supplies, Connectors, Sensors, Industrial Controls

    5296 TDS-EN.pdf


    5296 is a Two-Part Addition-Type Potting Silicone. It has a long operating time at room temperature and if heated can accelerate the curing speed. It has excellent thermal stability, especially high temperature-stability. When it has completely cured, the rubber elasticity can maintain at a wider temperature range,and its insulating quality is also very excellent too. It has very low thermal expansion, good water resistant and ageing resistant. It has low viscosity and high thermal conductivity, and is compatible with most electrical insulating materials.


    Applications
    All kinds of electrical components of thermal conductivity, flame retardant potting, such as photovoltaic inverters, LED drive power.charging piles, automotive electronics, NEV power, controllers etc.


    Product Features

    1) High thermal conductivity and flowability

    2) Both room temperature and heat curing

    3) Good weather and aging resistance

    4) Excellent insulation properties

    5) Flame retardant UL94V-0

    6) Maintains rubber elasticity from -50°C to 200°C

    7) RoHS Directive


    Technical parameters

    Reference standard1ItemUnitValue
    Physical properties before curing (25±2℃, 60%±5%RH)
    Q/HTXC 2Appearance (A)--Grey fluid
    Appearance (B)--White fluid
    GB/T2794Viscosity (A)mPa·s3500~5500
    Viscosity (B)mPa·s2800~4800
    GB/T13354Density (A)g/cm31.91±0.05
    Density (B)g/cm31.95±0.05
    Physical properties after curing (25±2℃, 60±5%RH, A:B=1:1)
    Q/HTXC 2Operating timemin60~180
    Q/HTXC 2Gel time (25℃)h3~5
    Q/HTXC 2Gel time (80℃)min≤30
    GB/T 531Hardness (ShoreA)--30~40
    Q/HTXC 2Dielectric strengthKV/mm≥18
    Q/HTXC 2Volume resistivityΩ·cm≥1.0×1014
    IS0 22007-2Thermal conductivityW/m·K0.9~1.0

    Cautions
    Store the product in a sealed container, and keep it away from children for storage.

    The glue will not cure if exposed to a certain amount of the following chemicals:

    Organic compounds of N, P, and S, ionic compounds of Sn, Pb, Hg, As, etc.;

    Compounds containing alkyne and polyvinyl.

    To avoid the above problem, Any residual rosin on the circuit board should be wiped clean when using the glue, and use soldering tin with low lead content.

    This product is non-hazardous. Please consult the MSDS of the product for safety information.


    Packaging

    25kg/barrel, 10kg/barrel
